7
ASSEMBLY
In order to best protect the generator while in the package, this product comes with some
components disassembled. Please complete the following assembly steps before proceeding to use
the generator. For ease of assembly, we recommend attaching the components in the order listed in
this manual.
If after reading this section, you are unsure about how to perform any of the steps, please call (800)
232-1195 M-F 8-5 CST for customer service.
Attaching the Carrying handle
• Remove the 2 bolts from the tool pouch. Bolts have lock washers attached.
• Assemble the screwdriver included in tool pouch.
• Place the 2 bolts into the carrying handle.
• Position the handle over the threaded holes in the fuel tank.
• Tighten bolts using the screwdriver until bolts are snug.
GENERATOR PREPARATION
Using the Generator for the First Time
The following section describes steps necessary to prepare the generator for use. If after
reading this section, you are unsure about how to perform any of the steps please call
(800) 232-
1195 M-F 8-5 CST
for customer service. Failure to perform these steps properly can damage
the generator or shorten its life.
Step 1 – Mixing Fuel for 2-Stroke Engines
Oil and Fuel Specifications
a. Oil
To operate the engine, use a high quality 2 Cycle oil mixed with unleaded gasoline at a
ratio of 32 to 1. See table below for mixing amounts.
Note: Use NMMA or TC-WII or TC-W3 or JASO FB or FASO FC classified oil in the
mixture.
b. Gasoline
Use unleaded regular, unleaded premium, or gasoline containing 10% ethanol. Fuel must
be fresh and clean. Never use gasoline stored for long periods.
2-Stroke 900 Rated Watt Generator
Item # 56100
Owner’s Manual
Manual del Propietario
FEATURES:
• 1000 Surge Watt Output
• 900 Rated Watt Output (7.5Amps at 120Volts)
• 2 HP Single Cylinder 2-Stroke Engine
• One (1) 120Volt AC Receptacle
• One (1) 12Volt DC Receptacle
• Circuit Reset for AC Receptacle
• Circuit Reset for DC Receptacle
• One (1) Gallon Fuel Tank
• Fuel Mix 32 to 1 (Gasoline to Oil)
• Five (5) Hours Run Time at Half Load
• EPA Certified
• Low Noise Generator
• Spark Arrestor
