20
!
Optional Accessories
Installation of the electrical junction box is required if using
a blower or remote. To install:
•
Uncoil the junction box cord and feed the end of the
cord through the hole on the right side of the base pan.
•
Turn the junction box at a 45-degree angle and insert it
into the sidewall of the base pan.
•
Turn junction box so it is flush with sidewall and screw
into place with the screw provided in the manual bag.
•
Gently pull the end of the cord until cord is tight. Place
the strain relief on the cord and then place it into hole on
base pan.
•
Plug the cord into a convenient outlet. An electrician
may install an outlet box inside the fireplace. Place the
outlet in the lower, back corner of the fireplace supplied.
Make sure fan doesn’t touch back wall.
Fan Option (FB-IN & FB-Grand ONLY)
On units already installed removal of decorative front, sur-
round and gas insert is required.
• Detach flexible liner from back of unit.
• Remove the four screws on the coverplate (see Figure 11).
• Bend up the tabs on the base pan (see Figure 10).
• Place the blower in between the bend up tabs.
• Install and wire the blower per instruction shipped with
the fan.
• The ground wire of the fan can clip on the side of the
base pan.
• Reinstall the cover plate back on the unit. Make sure
the fan does not make contact with the back wall.
Find owners guides and pdf support documentation for blenders, coffee makers, juicers and more. Free Proctor-Silex Coffeemaker User Manuals ManualsOnline.com Go. View & download of more than 382 Proctor-silex PDF user manuals, service manuals, operating guides. Coffee maker user manuals, operating guides & specifications. View and Download Proctor-Silex 46888 user manual online. ProctorSilex 46888: User Guide. 46888 Coffee Maker pdf manual download. View online Operation & user’s manual for Proctor-Silex 43501 Coffee Maker or simply click Download button to examine the Proctor-Silex 43501 guidelines offline on your desktop or laptop computer. Proctor silex coffee maker 43502 manual. Download 68 Proctor-silex Coffee Maker PDF manuals. User manuals, Proctor-silex Coffee maker Operating guides and Service manuals.
Figure 9.
Junction box installation
JUNCTION
BOX
SIDEWALL
FEED PLUG
THROUGH HOLE
Download 147 New holland Tractor PDF manuals. User manuals, New holland Tractor Operating guides and Service manuals. New Holland was founded in 1895 in the Pennsylvania borough of the same name. Known for dependability, New Holland became famous for making a tractor that the owner could perform all the service and repairs themselves using an official New Holland Service and Repair Manual. A factory New Holland Service Manual is the only real choice. The original free New Holland operators manual is helpful for becoming familiar with the operation and minor maintenance of your New Holland Tractor. But, an authentic New Holland Tractor service manual is a must-have item for both the professional and the do-it-yourself mechanic. New holland tractor manual download.
INSERT STRAIN RELIEF
AROUND CORD IN THIS END
FROM OUTSIDE OF UNIT
SCREW
PROVIDED
Figure 10. Fan Wiring Diagram
NOTE: IF ANY OF THE ORIGINAL WIRE AS SUP-
PLIED WITH THE APPLIANCE MUST BE RE-
PLACED, IT MUST BE REPLACED WITH TYPE
105
0
C RATED WIRE.
WARNING: MUST USE THE CORD SUPPLIED
WITH THE J-BOX.
JUNCTION BOX
VARIABLE SPEED CONTROL
TEMPERATURE
SENSOR SWITCH
WHT
GRN
BLK
BLK
110-120 VAC
BLOWER
BLOWER RECEPTACLE
BLK
BLK
BLK
BLK
WHT
GROUND
WHT
BLK
BLK
BLK
FAN
TEMPERATURE
SENSOR SWITCH
SPEED CONTROL
(RHEOSTAT)
JUNCTION
BOX
GROUND WIRE
(ATTACH TO ANY
METAL SURFACE)
Heat N Glo Fireplace Insert Manual
Figure 11.
FAN
COVER
PLATE
GROUND
WIRE
